Quick Details

  • Place of Origin: Shanghai, China (Mainland)
  • Brand Name: NSJ
  • Model Number: CGA1500-1-1
  • Type: Air Pump
  • Average Air Consumption: 6.8 bar(100PSI)~10bar (145PSI)
  • Maximum Torque: 625KG-800KG
  • No-Load Speed: NON
  • Item Name: air spray gun for polyurethane foam in 1500ml cartridge
  • Color: Black/silver grey/red/blue/golden
  • Material: Aluminum & Iron materials
  • capacity: 750ml*750ml two-component cartridges
  • Power source: Air
  • Weight: 3.6KGS
  • glue ratio: 1:1

Packaging & Delivery

Packaging Details: air spray gun for polyurethane foam in 1500ml cartridge
Carton size : 40*44*19/pcs ,
Package: 1pcs/ctn
Weight:7-8kg/pcs

air spray gun for polyurethane foam in 1500ml cartridge



Product Description

 Two-component Caulking Gun with Metal Material, Pneumatic

 It is widely used in construction, Tunnel & Railway, Roofing & waterproofing, Fastening & Anchoring, Decoration, Stones and Electronic fields etc.



Material: Reinforced Nylon Handle, Metal Cartridge Holder, Aluminium Air Cylinder, Plastic Front Handle





Technical data:



Thrust: 625KG-800KG

Air Supply: 6.8 bar(100PSI)~10bar (145PSI)

Male: 1/4”  BSP Air Supply Fitting (EU)

          1/4”  NPT Air Supply Fitting (US)

Packaging: Packed individually

Available color: Grey, Black, Blue, Red, Golden



Size:



Available Size

Capacity

Cartridge

Package

CGA400

400ml

Two-component

1PCS/CTN

CGA600

600ml

Two-component

1PCS/CTN

CGA675

675ml

Two-component

1PCS/CTN

CGA750

750ml

Two-component

1PCS/CTN

CGA825

825ml

Two-component

1PCS/CTN

CGA900

900ml

Two-component

1PCS/CTN

CGA1050

1050ml

Two-component

1PCS/CTN

CGA1350

1350ml

Two-component

1PCS/CTN

CGA1200

1200ml

Two-component

1PCS/CTN

CGA1500

1500ml

Two-component

1PCS/CTN











Operating Steps





Step1: Insert cartridge. Push the cartridge into the cartridge sleeve and press it down until it clicks into position.

Step 2: Assemble static mixer. After cartridge is well installed, remove the cartridge stopper and cap nut, and fasten static mixer using the cap nut on the cartridge outlet thread.

Step3: Connect pneumatic caulking gun to the compressed air supply6.

Connect the compressed air hose to the compressed air inlet via the quick-release coupling, and then connect this compressed air hose to air compressor. Please make sure that there is no air released in the connector.

Step 4: Dispensing the adhesives.

     Open the switch of air compressor, and press the trigger7of Pneumatic caulking gun. Dispensing is started, and the piston rod will move forward. The dispense volume can be controlled by means of the pressure regulating valve 8. When the trigger is released, dispensing stops.

a) Pull the pressure regulating valve.

b) Adjust the dispense volume by turning the adjuster in the “+”or “-”direction.

c) Press the pressure regulating valve to confirm the set value.

Step 5: Removing the cartridge

       Release the trigger and press the red button--- Retract piston rod9 until the piston rod have retracted to the back end-stop, and then remove the cartridge from the cartridge sleeve.





Attentions:



1. Never insert the cartridge while the dispenser is connected to air compressor.

2. If the cartridge is not in the correct position, the trigger cannot be pressed.

3. Don’t remove, tamper or manipulate pressure regulating valve and strictly respect pressure limits.

4. Don’t connect the applicator to an air compressor that exceeds 115PSI. (Or Air pressure of compressor should not exceed 115PSI or 8bar.)

5. Don’t immerse the gun in solvent.

6. Don’t operate the gun with loose, broken or missing parts.

7. Don’t carry the gun by the air pipe.

8. Don’t use damaged cartridges or the wrong type of cartridge in the applicator.

9. Don’t point the applicator at another person.

10. Don’t disassemble the handle and adjust the safety valve inside.

11. Don’t use a static mixer that has material inside it that has cured.

12. Don’t use partially extruded cartridges unless you use a new static mixer and know that there is no cross-contamination.

13. Don’t use expired material or material that has cured.







Company Information

Since 2006, Shanghai NSJ Hardware Ltd. specializing in two-component systems:

Two-component Cartridges and static mixersTwo-component Caulking gunsTwo-component Filling machine and some other products such as single series cartridge and gun, blow pump, plastic or metal brushes.



Shanghai NSJ Hardware Ltd is a manufacturer, Passed the international certificate as CE, ISO.

Provide OEM and ODM service to overseas customers.



Export to more than 15 countries in North America, Europe, the Middle East, Southeast Asia, Africa, South America and areas.



NSJ products are involve to Dental, Anchoring, Bonding, Coating and Automotive sealing and other field by full range of sizes, which is the most in China and developing continuously.



As a manufacturer, we also provide all international standard products and customize systems.

Shanghai NSJ Hardware Ltd will provide all customers at home and abroad perfect solutions with favorable prices and professional service.



Our Services



24 hours online service

     - Enquiry will be replied in 2 hours.

     - Professional Recommendation

     - 1%-2%Spare Parts.

     - Free parts for any breakdown with convincing evidence.

     - Our mission is to provide worldwide customers with the Chinese two-component package system and solution.





FAQ



Q1: Can I have a sample for testing?

     A: Since all is standard size, we do not suggest to buy samples and pay high shipping charges.          We supply free samples for plastic cartridge, static mixers, but guns samples are 20% higher than regular order.



Q2: Can I print my logo on the gun body?

    A: Yes,OEM and ODM are available for us.

        But you should send us the Trademark authorization letter.



Q3: How can I get the after-service?

    A: We will send you the spare parts by free if the problems caused by us.

        If it is the men-made problems, we also send the spare parts, but you should pay.



Q4: Do you have inspection?

    A: 100% self-inspection before packing and also 100% force test.



Q5: Can we customize our perferred colors
    A: Yes, if the items are meet QTY 100units.



Q6: Can I have a visit to your factory before the order?

    A: Sure,welcome to visit our factory.

        Add.: 1118 Huateng Rd, Huaxin Town, Qingpu District, Shanghai, China

      Our factory is near Hongqiao Airport. We can pick you up in the airport.

      Hotel booking service is available.
